TerraCORE is an internationally recognized, state-of-the-art reinforced wall panel cladding system that incorporates the natural beauty of large-format porcelain, granite, marble, limestone, travertine, onyx, and sandstones with an array of CORE materials. terracore's crown jewel is the reinforced, lightweight honeycomb panel cladding system that can be used anywhere and everywhere dimensional stone or porcelain can be used.
CODE COMPLIANCE
INTERTEKCCR-1114 • NFPA 285 • MIAMI DADE
TerraCORE-HCT – Honeycomb Reinforced Stone Panel
TerraCORE-HCT is an aluminum honeycomb substrate bonded to a natural, thin stone veneer. Sandwiched between the honeycomb and the stone is a 1mm thick, highly elastic, interwoven bi-directional fiberglass cloth that is saturated with a high strength epoxy resin that is used to bond these two materials together. Once cured, this is the strongest and most rigid CORE backing that TerraCORE Panels has to offer. TerraCORE-HCT is primarily used as an exterior application; however, it can be used as an interior panel as well. TerraCORE-HCT has an impact strength up to 60 times stronger and weighs 80% less than 2cm stone. The honeycomb is typically 3/4″(18mm) thick, but may vary in thickness depending on the architectural design intent, project site limitations, and/or restrictions. When used as an exterior panel, the aluminum backing lends both rigidity and stability to the overall flatness of the panel, while simultaneously acting as a radiant barrier. Competitors that use a fiberglass cloth back skin naturally bow, making them harder to install using interlocking channels and virtually impossible to adhere.
TerraCORE-HCI – Honeycomb Reinforced Stone Panel
TerraCORE-HCI is an aluminum honeycomb substrate bonded to a natural, thin stone veneer. TerraCORE-HCI can only be used for interior applications. TerraCORE-HCI has an impact strength far greater than dimensional stone and weighs approximately 80% less than 2cm stone. The honeycomb is typically 3/8″(9mm) thick, however, it may vary in thickness depending on the architects design intent, project site limitations and or restrictions. The aluminum back skin lends rigidity and stability to the overall flatness of the panel. Others that use a fiberglass cloth back skin naturally bow making them harder to install using interlocking channels and virtually impossible to adhere.
TerraCORE-CR – Ceramic Tile
TerraCORE-CR is a 3/8″(9mm) ceramic tile laminated to the back of a 1/8″(3mm) natural, thin stone panel for an overall thickness of 1/2″(12mm). This backing is fantastic for all interior floor applications and can be manufactured into any size up to a 32″ x 32″ piece. Instead of having to deal with epoxies or sealants, TerraCORE-CR installs perfectly level, using a water-based mud. TerraCORE-CR eliminates lippage and does not curl like most 3/8″ stone tiles. In fact, the thicker the stone tile, the weaker the stone actually becomes.
TerraCORE-GL – Glass
TerraCORE-GL is a hardened glass 1/4″(6mm) sheet, laminated to a translucent stone using clear epoxies. These composite translucent onyx or light marbled panels are great for light coves, columns, ceiling panels, faux windows, cabinet walls, bar tops, accents, security screens, wall sconces, and / or feature walls. TerraCORE-GL varies in thickness depending on the size of the stone panel it’s laminated to, but generally it is 1/2″(12mm) to 3/4″(18mm) thick.
TerraCORE-FB – Fiberglass Backed
TerraCORE-FB is a fiberglass backed 1/16″(1mm) thick, highly elastic, interwoven bi-directional sheet bonded to a 1/4″(6mm) thick stone panel for an overall thickness of 5/16″(8mm). It has a maximum size of 4′- 7 1/8″ x 9′- 2 1/4″ (1400 mm x 2800 mm) and is only about 22kg/m2. Its flexural strength tested at 10.4 mm.
